WS34A

Availability:
Quantity:
Inquire Add to Basket

Model WS34A
Displacement 34ml/r
Range of Voltage DC   380V DC 600V
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
Oil POE 68 POE 68 POE 68 POE 68 POE 68 POE 68
Charge Amount 120ml 120ml 120ml 120ml 120ml 120ml
Range of Roation 1000-6000rpm 1000-6000rpm 1000-6000rpm 1000-6000rpm 1000-6000rpm 1000-6000rpm
Speed Range PWM/CAN/LIN PWM/CAN/LIN PWM/CAN/LIN PWM/CAN/LIN PWM/CAN/LIN PWM/CAN/LIN
Rated Cooling Capacity 5600W（6000rpm） 5600W（6000rpm） 5600W（6000rpm） 5600W（6000rpm） 5600W（6000rpm） 5600W（6000rpm）
Rated Power Consumpiton 2545W（6000rpm） 2545W（6000rpm） 2545W（6000rpm） 2545W（6000rpm） 2545W（6000rpm） 2545W（6000rpm）
COP 2.2 2.2 2.2 2.2 2.2 2.2
Maximum Current 15A 15A 15A 10A 10A 10A
Weight 6.1KG 6.1KG 6.1KG 6.1KG 6.1KG 6.1KG
Test conditions: Suction pressure 0.3MPa (A), exhaust pressure 1.5MPa (A), superheat 10 ° C, and supercooling 5 ° C
